MODEL

YY-D-200-5 V-G

OUTPUT

DC VOLTAGE

5V

RATED CURRENT

40A

CURRENT RANGE

0～40A

RATED POWER

200W

RIPPLE&NOISE

≤100mV

VOLTAE ADJ.RANGE

±1%

VOLTAGE TOLERANCE

±1%

LINE REGULATION

±0.5%

LOAD REGULATION

±2.0%

SET UP TIME

50mS

HOLD UP TIME

20mS

INPUT

VOLTAGE RANGE

200V～240V

FRE.RANGE

47Hz～63Hz

EFFICIENCY

88%

INRUSH CURRENT

≤40A

LEAKAGE CURRENT

≤2.0mA

PROTECTION

INPUT UNDERVOLTAGE

150V～170V

INPUT OVER VOLTAGE

270V～280V

INPUT OVER CURRENT

4A

OUTPUT OVER VOLTAGE

5.75V～7.5V(Re-start）

OUTPUT LIMIT CURRENT

61A～70A

OVER TEMPERATURE

105℃±5℃

THERMAL METHODS

Cooled by air

ENVIRONMENT

WORKING TEMP.

—30℃～+60℃

WORKING HUMIDITY

20～90%RH

STORAGE TEMP.,HUMDITY

—40℃～+80℃,10～95%RH

TEMP.COEFFICIENT

±0.03%/℃（0～50℃）

VIBRATION

10-300MHz,1G,10 min./1 cycle，

Period for 60min each axes.

SAFETY

SAFETY STANDARDS

GB4943、UL60950、EN60950

EMC STANDARDS

GB9254、EN55022A

WITHSTAND VOLTAGE

I/P-O/P:3KVAC/3mA/1min

I/P-FG:1.5KVAC/3mA/1min

O/P-FG:0.5KVAC/3mA/1min

ISOLATION RESISTANCE

I/P-O/P:100MΩmin/500VDC

CERTIFICATION

CQC/ CE/ CB/ ROHS/CCC

OTHERS

DIMENSION

210*62*31mm
